## Count overlapping days across multiple date ranges

This post demonstrates a formula in cell D16 that counts overlapping dates across multiple date ranges. The date ranges are specified in the Excel Table column Start and End (cell range B3:B12 and C3:C12), see image above.

To the right is a part of a calendar with date 1 to 14, the gray cells are days based on the corresponding date range. The x's are dates that overlap another date.

Row 13 contains the sum of these gray days column-wise, row 14 contains 1 or 0 (zero) indicating if the date contains a date range that overlaps another date range. Cell S14 contains a total of these overlapping dates. This is only demonstrated to show that the calculation is in fact correct.

NC asks:

*Thanks a tonne, Oscar. It took me about 8 hours to work through this formula piece by piece, play with it, and come to grips with its basics. Your example was clear and very useful, and this has allowed me to do big, very useful data analysis for the company that employs me. It applies to thousands of people. You're an unsung hero.*

*Actually just realized that I really need what you said you'd "save for a future post" (actually total number of overlapping dates). I guess I'll try to figure that out. Still... couldn't have gotten this close without you.*

Answer:

Thanks NC, here comes that "future" post. Array formula in cell D16:

To enter an array formula you copy above formula and paste to a cell. Press and hold CTRL and Shift simultaneoulsy, then press Enter once. Release all keys.

The formula is now surrounded with curly brackets, don't enter these characters yourself, they appear automatically. {=formula}

### Explaining formula in cell D16

#### Step 1 - Create array

The power of sign ^ converts all dates in Table column Start to 1, you can also use the POWER function, however, to keep the formula as small as possible I use ^.

TRANSPOSE(Table1[Start]^0)

becomes

TRANSPOSE({38354; 38359; 38356; 38362; 38364; 38353; 38364; 38356; 38358; 38364}^0)

becomes

TRANSPOSE({1; 1; 1; 1; 1; 1; 1; 1; 1; 1})

The TRANSPOSE function converts a vertical range to a horizontal range, or vice versa.

TRANSPOSE({1; 1; 1; 1; 1; 1; 1; 1; 1; 1})

returns

{1, 1, 1, 1, 1, 1, 1, 1, 1, 1}

This array is needed in the first argument in the MMULT function.

#### Step 2 - Create an array containing dates

This step calculates the dates needed based on the earliest and latest date in columns Table1[Start] and Table1[End].

(TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B,MAX(Table1[End])-MIN(Table1[Start])+1))-1)

becomes

(TRANSPOSE(MIN({38354; 38359; 38356; 38362; 38364; 38353; 38364; 38356; 38358; 38364})+ROW(B1:INDEX($B:$B,MAX(Table1[End])-MIN(Table1[Start])+1))-1)

becomes

(TRANSPOSE(38353+ROW(B1:INDEX($B:$B,MAX(Table1[End])-MIN(Table1[Start])+1))-1)

becomes

(TRANSPOSE(38353+ROW(B1:INDEX($B:$B,MAX({38356; 38360; 38358; 38365; 38366; 38354; 38365; 38356; 38359; 38364})-MIN(Table1[Start])+1))-1)

becomes

(TRANSPOSE(38353+ROW(B1:INDEX($B:$B,38366-MIN(Table1[Start])+1))-1)

becomes

(TRANSPOSE(38353+ROW(B1:INDEX($B:$B,38366-38353+1)))-1)

becomes

(TRANSPOSE(38353+ROW(B1:INDEX($B:$B,13+1)))-1)

becomes

(TRANSPOSE(38353+ROW(B1:INDEX($B:$B,14)))-1)

becomes

(TRANSPOSE(38353+ROW(B1:$B14))-1)

becomes

(TRANSPOSE(38353+{1; 2; 3; 4; 5; 6; 7; 8; 9; 10; 11; 12; 13; 14})-1)

becomes

(TRANSPOSE({38354; 38355; 38356; 38357; 38358; 38359; 38360; 38361; 38362; 38363; 38364; 38365; 38366; 38367})-1)

becomes

(TRANSPOSE(38353+{0; 1; 2; 3; 4; 5; 6; 7; 8; 9; 10; 11; 12; 13})

and returns

{38353, 38354, 38355, 38356, 38357, 38358, 38359, 38360, 38361, 38362, 38363, 38364, 38365, 38366}

#### Step 3 - Check which dates are later or equal to dates in Table column Start

(TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B,MAX(Table1[End])-MIN(Table1[Start])+1))-1)>=Table1[Start]

becomes

{38353, 38354, 38355, 38356, 38357, 38358, 38359, 38360, 38361, 38362, 38363, 38364, 38365, 38366}>=Table1[Start]

becomes

{38353, 38354, 38355, 38356, 38357, 38358, 38359, 38360, 38361, 38362, 38363, 38364, 38365, 38366}>={38354; 38359; 38356; 38362; 38364; 38353; 38364; 38356; 38358; 38364}

and returns this array:

I have added the dates horizontally and vertically to make this picture more easy to understand.

#### Step 4 - Repeat step 2 and 3 with Table column End

((TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B,MAX(Table1[End])-MIN(Table1[Start])+1))-1))<=Table1[End]))>1)

returns this array:

#### Step 5 - Multiply arrays

(TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B, MAX(Table1[End])-MIN(Table1[Start])+1))-1)>=Table1[Start])*((TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B, MAX(Table1[End])-MIN(Table1[Start])+1))-1))<=Table1[End])

returns this array:

#### Step 6 - Sum values column-wise

MMULT(TRANSPOSE(Table1[Start]^0), (TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B, MAX(Table1[End])-MIN(Table1[Start])+1))-1)>=Table1[Start])*((TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B, MAX(Table1[End])-MIN(Table1[Start])+1))-1))<=Table1[End]))

returns

{1, 2, 1, 3, 1, 2, 2, 1, 0, 1, 1, 4, 3, 1}

#### Step 7 - Check if value in array is larger than 1

MMULT(TRANSPOSE(Table1[Start]^0), (TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B, MAX(Table1[End])-MIN(Table1[Start])+1))-1)>=Table1[Start])*((TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B, MAX(Table1[End])-MIN(Table1[Start])+1))-1))<=Table1[End]))>1

becomes

{1, 2, 1, 3, 1, 2, 2, 1, 0, 1, 1, 4, 3, 1}>1

and returns

{FALSE, TRUE, FALSE, TRUE, FALSE, TRUE, TRUE, FALSE, FALSE, FALSE, FALSE, TRUE, TRUE, FALSE}

#### Step 8 - Convert boolean values to their numerical equivalents

(MMULT(TRANSPOSE(Table1[Start]^0), (TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B, MAX(Table1[End])-MIN(Table1[Start])+1))-1)>=Table1[Start])*((TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B, MAX(Table1[End])-MIN(Table1[Start])+1))-1))<=Table1[End]))>1)*1

becomes

{FALSE, TRUE, FALSE, TRUE, FALSE, TRUE, TRUE, FALSE, FALSE, FALSE, FALSE, TRUE, TRUE, FALSE}*1

and returns

{0, 1, 0, 1, 0, 1, 1, 0, 0, 0, 0, 1, 1, 0}

#### Step 9 - Sum overlapping dates

SUM((MMULT(TRANSPOSE(Table1[Start]^0), (TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B, MAX(Table1[End])-MIN(Table1[Start])+1))-1)>=Table1[Start])*((TRANSPOSE(MIN(Table1[Start])+ROW(B1:INDEX($B:$B, MAX(Table1[End])-MIN(Table1[Start])+1))-1))<=Table1[End]))>1)*1)

becomes

SUM({0, 1, 0, 1, 0, 1, 1, 0, 0, 0, 0, 1, 1, 0})

and returns 6 in cell D16.

### Count overlapping days across multiple date ranges with condition

This formula takes into account the condition specified in cell E15 as well, the formula counts overlapping dates based on date ranges that has a cell in column A which is equal to the condition in cell B14.

Formula in cell E15:

The only difference with the formula above is this part:

($A$2:$A$11=$B$14)

It is a logical expression that returns an array containing TRUE or FALSE if equal to value in cell B14.

Count unique distinct values that meet multiple criteria

This post demonstrates how to build an array formula that counts unique distinct values based on criteria. What's on this […]

This article describes how to count unique distinct values. What are unique distinct values? They are all values but duplicates are […]

Count Conditionally Formatted cells

This article explains how to count cells highlighted with Conditional Formatting (CF). The image above shows data in cell range […]

Excelxor is such a great website for inspiration, I am really impressed by this post Which numbers add up to […]

This article demonstrates a scoreboard, displayed to the left, that sorts contestants based on total scores and refreshes instantly each […]

How to extract rows containing digits [Formula]

This article describes a formula that returns all rows containing at least one digit 0 (zero) to 9. What's on […]

Highlight records based on overlapping date ranges and a condition

adam asks: Hi, I have a situation where I want to count if this value is duplicate and if it […]

Identify overlapping date ranges

The formula in cell F6 returns TRUE if the date range on the same row overlaps another date range in […]

How to calculate overlapping time ranges

I found an old post that I think is interesting to write about today. Think of two overlapping ranges, it […]

### 6 Responses to “Count overlapping days across multiple date ranges”

### Leave a Reply

### How to comment

**How to add a formula to your comment**

<code>Insert your formula here.</code>

**Convert less than and larger than signs**

Use html character entities instead of less than and larger than signs.

< becomes < and > becomes >

**How to add VBA code to your comment**

[vb 1="vbnet" language=","]

Put your VBA code here.

[/vb]

**How to add a picture to your comment:**

Upload picture to postimage.org or imgur

Paste image link to your comment.

**Contact Oscar**

You can contact me through this contact form

[…] The value in cell A11 is wrong because of this, only 9 dates are overlapped. There is a formula for this scenario also but I'll save it for a future post. […]

This formula is almost perfect for what I need. Is there a way to add an "If" statement so that the overlap will calculate dependent on an email address. I need to calculate overlap by person for 9000 people.

Christyn Lewandowski,

great question. I have added more content to this article that answers your question.

What about the opposite? I'd like a sum of dates that are NOT overlapping. For example: a ticket's dates of validity compared to dates of actual use, when some of the days were not included with the ticket.

Ticket start: 01/01/2010 Ticket end 01/05/2010 Actual use start: 01/04/2010 Actual use end: 01/07/2010. The result should be 2, because they used the service on Jan 6 and Jan 7, when those dates were not covered by their ticket.

Thanks!!!!!

Excel Noob,

Formula in cell F3:

=MEDIAN(B3,C3+1,E3+1) - MEDIAN(B3,C3+1,D3)

Units contained in a range that overlap another range

Oscar, this is amazing stuff! I did have a follow-up question on this method. I have data that decades - I need to calculate the quantity of days that overlap for each row (or project). For example, if I have four concurrent projects, each one as a row, I need to calculate the total quantity of days that the other three projects might overlap. This figure would need to be calculated for each row. How might you recommend proceeding? Thank you for your time!
